Features

  • Continuous soil profile (1-5 cm depth increments)
  • Multiple parameters in a single test:
    • tip resistance (qt)
    • sleeve friction (fs)
    • dynamic pore pressure (Ud)
    • static pore pressure (Ueq)
    • temperature
    • inclination
  • 5, 10, 15, 20, and 40 cm2 sizes (cross sectional area)
  • Wide range of load and pressure transducer capacities to maximize accuracy in all soil types
  • Custom project specific features as required
  • Industry leading calibration and certification procedures
  • Pre-project or pre-hole calibration verification, as required
  • Wireline deployment options for mine fluid deposits (CT09)

Advantages

  • Highly accurate and repeatable
  • Cost effective and value added
  • Rapid and efficient testing - 2 cm / second penetration rates, >150 m or 500 ft per day
  • Minimally invasive with no soil cuttings (1.75 in. / 43.7 mm diameter)
  • Continuous soil profile
  • Pore pressure response and groundwater evaluation
  • Full suite of published correlations to geotechnical design parameters
  • Direct design applications

Applications

  • Deep and shallow foundation design
  • Liquefaction evaluation (static and cyclic)
  • Slope stability
  • Geotechnical soil parameter evaluation
  • Mine tailings
  • Geo-environmental site characterization (contaminated sites)
  • Marine site characterization
